UV Laser marking machine
UV is one of the laser marking machines, is also a newly developed laser processing technology. Is a cold process that has been minimized in terms of thermal effects. This is a big leap in laser technology, its marking effect is more detailed, mainly used for fiber laser marking difficult to mark materials (such as crystals, high flame retardant material HDPE)
Description
- laser wavelength 355nm
- not limited by material, can be in glass, crystal, phone case, PVC, metal, stone, leather and other color photo printing, also known as universal laser marking machine.
- especially suitable for high-end, meticulous production and processing
- Can customize flight, assembly line and dynamic styles according to product requirements
|
Technical Parameters |
|
|
Laser power |
3W 5W 10W 20W optional |
|
Laser wavelength |
355nm |
|
Beam quality M² |
<1.1 |
|
Laser Q-switched frequency |
0 ~ 100kHz |
|
Pulse Width |
<20ns @ 50khz |
|
Operating temperature |
18-40 degrees |
|
cooling method |
Water cooling |
|
Total power |
<4KW |
|
Repeat accuracy |
± 0.0001mm |
|
Machine power consumption |
<4kw |
|
electricity demand |
110V / 220V-50Hz / 60Hz (optional) |
