Laser Marking Machine For Wooden Crafts Chinese Chess
Carving wooden handicrafts with CO2 laser marking machine is faster and more precise than traditional handicraft engraving. The use time of laser marking machine can reach 40,000 hours without consumables, which greatly improves work efficiency. For mass production and engraving of complex patterns, make it easy and fast to change
Description
- The marking speed is fast, the lines are delicate, and the marking is clear and permanent
- Graphics, text and serial numbers can be edited by software
- No consumables, low cost and power saving
- Mark environmental protection and comply with ROHS standard
- According to human body engineering mechanics,the desktop design improves work efficiency of operators
|
Technical Parameters |
|
|
Model |
CL-CO2 |
|
Power |
20W/30W/50W/60W/100W |
|
Cooling Mode |
Air Cooling |
|
Marking Speed |
8000mm/s |
|
Laser Source |
Synrad/Coherent/Davi/Jingrui |
|
Minumum Line Width |
0.015mm |
|
Pulse Frequency |
1-25Khz/1-100Khz |
|
Minumum Character |
0.2mm |
|
Field Lens Brands |
Singapore Wavelength |
|
Laser Wavelength |
10.64μm |
|
Marking Area |
110*110mm / 140*140mm/ 175*175mm/210*210mm/300*300mm |
|
Environment |
5℃-45℃, clean or dust-free |
|
Control Card |
JCZ Brand EZCAD |
|
Power Supply |
AC220V / 110V plug |
|
Operating System |
Win XP /7/ 8/ 10 (32 bit, 64bit) |
|
Warranty |
1 year |
